ZJTEX ELECTRIC MOTOR
STANDARD DC MOTOR



MODEL
VOLTAGE
NO LOAD
AT MAXIMUM EFFICIENCY
STALL
TORQUE
OPERATING
RANGE
NOMINAL
SPEED
CURRENT
SPEED
CURRENT
TORQUE
OUTPUT
EFF
rpm
A
rpm
A
OZ-in
(g-cm)
W
%
OZ-in
(g-cm)
PC-260-10400
10.0-15.0
12.0V
CONSTANT
8800
0.040
7000
0.15
0.180
13.0
0.95
51.87
0.972
70
PC-260-08450
12.0-24.0
12.0V
CONSTANT
7700
0.035
5900
0.10
0.139
10.0
0.64
50.45
0.610
44
MODEL
VOLTAGE
NO LOAD
AT MAXIMUM EFFICIENCY
STALL
TORQUE
OPERATING
RANGE
NOMINAL
SPEED
CURRENT
SPEED
CURRENT
TORQUE
OUTPUT
EFF
rpm
A
rpm
A
OZ-in
(g-cm)
W
%
OZ-in
(g-cm)
PC-260S-12300P
6.0-12.0
12.0V
CONSTANT
8200
0.110
6360
0.29
0.389
28.0
1.83
52.60
1.760
127
PC-260S-2865P
3.6-6.0
6.0V
CONSTANT
18000
0.43
14300
1.38
0.486
35.0
5.13
61.96
2.291
165
PC-260S-09450P
12.0-24.0
12.0V
CONSTANT
5400
0.06
4000
0.13
0.264
19.0
0.80
51.28
1.110
80


MODEL
VOLTAGE
NO LOAD
AT MAXIMUM EFFICIENCY
STALL
TORQUE
OPERATING
RANGE
NOMINAL
SPEED
CURRENT
SPEED
CURRENT
TORQUE
OUTPUT
EFF
rpm
A
rpm
A
OZ-in
(g-cm)
W
%
OZ-in
(g-cm)
PC-280-18165P
4.5-12.0
12.0V
CONSTANT
16300
0.15
13400
0.52
0.347
25.0
3.45
55.13
1.945
140
MODEL
VOLTAGE
NO LOAD
AT MAXIMUM EFFICIENCY
STALL
TORQUE
OPERATING
RANGE
NOMINAL
SPEED
CURRENT
SPEED
CURRENT
TORQUE
OUTPUT
EFF
rpm
A
rpm
A
OZ-in
(g-cm)
W
%
OZ-in
(g-cm)
PC-280S-20150P
6.0-12.0
12.0V
CONSTANT
13400
0.16
11100
0.67
0.650
47.0
5.37
66.79
3.89
280
PC-280S-19160P
6.0-12.0
12.0V
CONSTANT
12000
0.14
9900
0.58
0.625
45.0
4.50
64.50
3.75
270
PC-280S-16200P
6.0-12.0
12.0V
CONSTANT
9800
0.12
8100
0.43
0.541
39.0
3.27
61.93
3.13
225
PC-280S-18165P
6.0-12.0
6.0V
CONSTANT
6300
0.12
4900
0.42
0.417
30.0
1.52
60.46
2.22
160


MODEL
VOLTAGE
NO LOAD
AT MAXIMUM EFFICIENCY
STALL
TORQUE
OPERATING
RANGE
NOMINAL
SPEED
CURRENT
SPEED
CURRENT
TORQUE
OUTPUT
EFF
rpm
A
rpm
A
OZ-in
(g-cm)
W
%
OZ-in
(g-cm)
UE-260-2670
1.5-3.0
3.0V
CONSTANT
12000
0.23
10000
1.00
0.208
15.00
1.54
51.30
1.278
92
UE-260-2295
1.5-4.5
3.0V
CONSTANT
9200
0.15
7500
0.60
0.167
12.00
0.92
51.30
1.000
72
UE-260-20120
1.5-4.5
3.0V
CONSTANT
7200
0.10
6000
0.42
0.153
11.00
0.68
53.74
0.860
62
MODEL
VOLTAGE
NO LOAD
AT MAXIMUM EFFICIENCY
STALL
TORQUE
OPERATING
RANGE
NOMINAL
SPEED
CURRENT
SPEED
CURRENT
TORQUE
OUTPUT
EFF
rpm
A
rpm
A
OZ-in
(g-cm)
W
%
OZ-in
(g-cm)
UC-260S-12300
12.0-24.0
24.0V
CONSTANT
17300
0.10
14000
0.37
0.541
39.00
5.62
62.00
2.780
200
UC-260S-09400
12.0-24.0
12.0V
CONSTANT
6000
0.07
4520
0.15
0.241
17.36
0.80
44.72
0.972
70
UC-260S-2670
3.0-6.0
4.5V
CONSTANT
14000
0.30
11600
1.35
0.403
29.00
3.45
56.81
2.500
180
