SERIES MOTOR

ZJTEX ELECTRIC MOTOR
SERIES MOTOR

Model	Rated Voltage	NO-load		Rated Opearation				Efficiency
	Rated Voltage	Speed	Current	Speed	Current	Torque		Efficiency
	V(AC)	rpm	A	rpm	A	g.cm	oz-in	%
48810B120-0001	120	19000	0.44	9900	0.65	250	3.5	33
48810B220-0001	120	19000	0.44	10000	0.65	250	3.5	33
48820B120-0001	230	22700	0.25	10300	0.38	250	3.5	30
48820B220-0001	240	22700	0.25	10300	0.38	250	3.5	29

CJ Series motor:Suitable for domestic appliances needs, for example Mixers, electric hand tools etc.

Mounting Arrangements

Model	A	B	C	D	E	F	G	H	J	K	L	M	N	Q
CJ2212-1117	26	12	17	20	F4.5	44	77	52	3.6	8	78	45	68	/
CJ1212-1623	26	12	17	20	F4.5	44	77	52	3.6	8	78	45	68	/
CJ2217-1320	26	17	17	20	F4.5	44	77	52	3.6	8	92	45	68	/

Technical Data

Model	Volts V	Freq. Hz	Rotation	No load		Rated Operation
Model	Volts V	Freq. Hz	Rotation	Speed rpm	Current A	Speed rpm	Current A	Torque g.cm	Output W	Eff. %
CJ2212-1117	220	50	CCW	23000	0.20	10500	0.38	275	29	38.5
CJ1212-1623	120	60	CCW	25000	0.38	11000	0.78	300	33	41
CJ2217-1320	220	50	CCW	23500	0.26	9600	0.64	650	64	45.8

HC Series motor: This model HC single-phase series motors have many advantages such as: small in shape, large in starting torque, safe and reliable in using and low in noise etc.. They are extensivly used as drive unit for all kinds of medical instruments, sealer small type bench drill, twist machine and other machinery. The power, voltage, revolution speed, size for extending part of axle end and shape for the motor can be worked out according to requirements of user.

HCL63-64	HCL84-14
HCL84-18	HCF80/28
HCB44/410	HCC78/15

Main technical parameter :

Model	Power W	Voltage V	Frequency HZ	Revolution r/min	Main usage
HCL63-64	25	220	50	4000	Being fit for medical instruments
HCL84-14	40	220	50	4000
HCL84-18	80	220	50	8000
HCB44/410	90(Input)	220	50	10000	Being fit for peeling thread machine and cutter machine
HCF80/28	90	220	50	8000	Being fit for sealer
HCC78/15	80	220	50	5000	Being fit for small type beach drill etc.

Serial Motors Of Food Equipments

These serial motors are mainly designed for food equipments such as meat micer, crasher, twist-machine etc.of various household electric appliance . Motors are characterised by : beautiful shape , small volume , large output with low power consuming, high revolution with large startion torque and low noise .With good operating performance and superior quality, the products are usually awarded "new product medal " and high quality certificate. Issued by the Ministry, the province and the Ningbo city. We will show our warmest welcome to both abroad and domestic customers to order.

HCQ-220	HCS70/113
HCQ63-2S	HCS71/38-2
HCS71/19	HCS70/312
HCS71/111-3

Main technical parameter :

Model	Input Power (W)	Voltage (V)	Frequency (Hz)	Revolution (r/min)	Rotating Direction of Axle Ends
HCQ-220	220	220/110	50	10000	C.C.W
HCS 70/113	200	220/110	50	13000	C.C.W
HCQ 63-2S	190/245	220/110	50	11500/8000	C.C.W
HCS 71/38-2	300/250	220/110	50	8000/5000	C.W
HCS 71/111-3	270	220/110	50	12000/10000/8000	C.C.W
HCS 70/312	300	220/110	50	12000	C.W
HCS 71/19	350	220/110	50	9000	C.W
