Rubber Magnet

Rubber Magnet

Rubber magnet are compounds of plastics or rubbers and magnetic powers. Their application field range from electronic & electric industry, daily necessary industry, electric motor stators and rotators, family education, printing and decoration, etc.

Characteristics

             * Light in special weight
             * Soft, elastic, stable
             * Easy to process

Properties of Rubber Magnet

TYPE	Remanence Br	Coercive Force Hcb	Intrinsic Coercive Hcj	Max. Energy Product (BH)max	Material	Application
R1 Isotropic Rubber	165~180mT	90~110KA/m	120~150KA/m	4.5~4.6KJ/m3	BaO.6Fe2O3 SrO.6Fe2O3 MIX CPE	Toy Stationary Holder
R1 Isotropic Rubber	1600~1800Gs	1130~1380Oe	1500~1880Oe	0.56~0.76MGOe	BaO.6Fe2O3 SrO.6Fe2O3 MIX CPE	Toy Stationary Holder
R2 Anisotropic Rubber	230~250mT	160~185KA/m	215~235KA/m	10.2~12.0KJ/m3	SrO.6Fe2O3 MIX NBR or CPE	Micro Motor Stationary Holder
R2 Anisotropic Rubber	2300~2500Gs	2000~2300Oe	2700~2950Oe	1.3~1.5MGOe	SrO.6Fe2O3 MIX NBR or CPE	Micro Motor Stationary Holder

Density
Hardness Br Temp. Coeff. Operation Temp. Spring
Productive Method

Unit G/cm3 SHORE D %/° C
° C

R1 3.6~3.7 30~45 -0.2 -40~80 Good Injection & Rolling

R2 3.6~3.7 30~60 -0.2 -40~80 Good Rolling

	Density	Hardness	Br Temp. Coeff.	Operation Temp.	Spring	Productive Method
Unit	G/cm3	SHORE D	%/° C	° C
R1	3.6~3.7	30~45	-0.2	-40~80	Good	Injection & Rolling
R2	3.6~3.7	30~60	-0.2	-40~80	Good	Rolling
