ZJTEX ELECTRIC MOTOR STANDARD DC MOTOR

MODEL	VOLTAGE		NO LOAD		AT MAXIMUM EFFICIENCY						STALL TORQUE
	OPERATING RANGE	NOMINAL	SPEED	CURRENT	SPEED	CURRENT	TORQUE		OUTPUT	EFF	STALL TORQUE
	OPERATING RANGE	NOMINAL	rpm	A	rpm	A	oz-in	(g-cm)	W	%	oz-in	(g-cm)
ZTA-1690	1.2-1.5	1.5V CONSTANT	9800	0.25	6730	0.55	0.045	3.26	0.23	27.38	0.145	10.40
ZTA-14120	1.5-3.0	3.0V CONSTANT	14600	0.25	10060	0.55	0.070	5.04	0.52	31.54	0.225	16.21
ZTA-10200	3.0-4.5	3.0V CONSTANT	9000	0.12	6020	0.24	0.043	3.07	0.19	26.35	0.129	9.27
ZTA1-09240	3.0-6.0	6.0V CONSTANT	17000	0.13	11460	0.27	0.070	5.05	0.59	36.78	0.215	15.49

* ZTA &ZTA1 ARE SIMILAR STRUCTURE BUT ZTA IS SINGLE BRUSH ZTA1 IS DOUBLE BRUSH (LOW NOISE TYPE)

MODEL	VOLTAGE		NO LOAD		AT MAXIMUM EFFICIENCY						STALL TORQUE
	OPERATING RANGE	NOMINAL	SPEED	CURRENT	SPEED	CURRENT	TORQUE		OUTPUT	EFF	STALL TORQUE
	OPERATING RANGE	NOMINAL	rpm	A	rpm	A	oz-in	(g-cm)	W	%	oz-in	(g-cm)
ZTB-1870	1.5-3.0	1.5V CONSTANT	8200	0.24	5790	0.58	0.074	5.32	0.32	36.58	0.252	18.09
ZTB-14120	1.5-3.0	3.0V CONSTANT	9800	0.14	7180	0.38	0.08	5.75	0.42	37.17	0.299	21.54
ZTB-10160	3.0-4.5	3.0V CONSTANT	7200	0.09	4970	0.20	0.047	3.39	0.17	28.83	0.153	10.97
ZTB1-10200	3.0-4.5	3.0V CONSTANT	6200	0.08	4280	0.18	0.049	3.53	0.15	29.02	0.159	11.40

*ZTB &ZTB1 ARE SIMILAR STRUCTURE BUT ZTB IS SINGLE BRUSH ZTB1 IS DOUBLE BRUSH (LOW NOISE TYPE)

MODEL	VOLTAGE		NO LOAD		AT MAXIMUM EFFICIENCY						STALL TORQUE
	OPERATING RANGE	NOMINAL	SPEED	CURRENT	SPEED	CURRENT	TORQUE		OUTPUT	EFF	STALL TORQUE
	OPERATING RANGE	NOMINAL	rpm	A	rpm	A	oz-in	(g-cm)	W	%	oz-in	(g-cm)
ZTC-2445	1.2-1.5	1.5V CONSTANT	9800	0.32	7180	0.89	0.095	6.83	0.50	38.0	0.358	25.72
ZTC-1870	1.5-3.0	3.0V CONSTANT	13200	0.22	9950	0.68	0.122	8.80	0.90	44.39	0.498	35.79
ZTC1-14120	1.5-4.5	3.0V CONSTANT	8400	0.10	6330	0.30	0.084	6.04	0.39	43.92	0.334	24.05
ZTC1-12145	3.0-4.5	3.0V CONSTANT	6700	0.06	5110	0.18	0.064	4.61	0.24	45.33	0.271	19.51

* ZTC & ZTC1 ARE SIMILAR STRUCTURE BUT ZTC IS SINGLE BRUSH ZTC1 IS DOUBLE BRUSH (LOW NOISE TYPE)
